| General |
| Input Ports | 4×HDMI Type A [19-pin female] |
| Output Ports | 4×HDMI Type A [19-pin female], 4×L/R audio out [3.5mm Stereo Mini-jack], 4×COAX audio out [RCA] |
| HDMI Audio Formats (Pass-through) | PCM2.0/5.1/7.1CH, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD |
| L/R Audio Formats | PCM 2.0 |
| Coax Audio Formats | LPCM 2.0, Dolby Digital / Plus, DTS 5.1 |
| HDMI Compliance | HDMI 2.0b |
| HDCP Compliance | HDCP 2.2/1.x |
| Video Bandwidth | 18Gbps |
| Video Resolution | Up to 4K2K@60Hz (4:4:4) |
| Control Ports | 1x TCP/IP [RJ45], 1x RS-232 [3-pin phoenix connector], 1x IR EXT [3.5mm Stereo Mini-jack] |
| Color Space | RGB, YCbCr 4:4:4/4:2:2/4:2:0 |
| Color Depth | 8-bit, 10-bit, 12-bit |
| HDR Formats | HDR10, HDR10+, Dolby Vision, HLG |
| ESD Protection | Human-body Model: ±8kV (Air-gap discharge), ±4kV (Contact discharge) |
| Housing | Metal Enclosure |
| Color | Black |
| Dimensions | 220mm (W) × 105mm (D) × 44mm (H) |
| Weight | 792g |
| Power Supply | Input: AC100~240V 50/60Hz, Output: DC12V/2.5A (Locking connector) |
| Power Consumption | 10W (max), 1.56W (Standby) |
| Operating Temperature | 0°C ~ 40°C / 32°F ~ 104°F |
| Storage Temperature | -20°C ~ 60°C / -4°F ~ 140°F |
| Relative Humidity | 20~90% RH (non-condensing) |
| Resolution/Cable Length | 4K60 – 10ft/3M; 4K30 – 32ft/10M; 1080P60 – 50ft/15M (Premium High Speed HDMI cable recommended) |
